Loren LVD Serious Screw Discharge Sludge Volute Decanter

 

Loren LVD Serious Screw Discharge Sludge Volute Decanter

Payment Type: T/T

Supply Ability: 15 Sets Per Three Months

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LVD-350

Brand: Loren

Status: New

Applicable Industry: Farms, Food &Amp; Beverage Shops, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction Works, Food &Amp; Beverage Factory, Energy &Amp; Mining, Other

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Bearing, Pressure Vessel

Place Of Origin: China

Productivity: 500l/Hour, 10000l/Hour, 750l/Hour, 100l/Hour, 1000l/Hour, 20000l/Hour, 2000l/Hour, 250l/Hour, 3000l/Hour, 125l/Hour, 200l/Hour, 4000l/Hour, 5000l/Hour, 7500l/Hour, 50000l/Hour, 2500l/Hour

Key Function: Screw Intrusion dewatering

Aspect Ratio: Large

Avoid The Double-Rotor: High-Speed Rotation

Auto PLC Control Or Adjust: Differential Speed And Torque

No: Odour Generated

Install& Operate: Easily

Widely Applied For: Different Types of Sludge

Optional For: Both Thickening & Dewatering

Labour Cost: Reduced

Applicant: Widely in Oil grease, Starc

Product Description

Loren LVD Serious Screw Discharge Sludge Volute Decanter

Waste Oil 3 Phase Horizontal Decanter Centrifuge Definition

Loren LVD Serious Horizontal Screw Centrifuge Is a Kind Of Screw Discharge Sedimentation Centrifuge Which Can Classify , Dehydrate and Clarify Solid Suspend Solid Phase Particle of 0.002-3mm. It Is Suitable For Separating Various Materials Under Different Working Conditions. Our Decanter Centrifuges Are Modular In Design And Can Be Used In a Wide Range Of Industries. Centrifuges Can Be Optimally Adjusted For Specific Applications. Applications Range From Sludge Dewatering To Classification Or Wet Classification To Solid Classification.

High Speed Industrial Horizontal Extraction Centrifuge Composition

It is Mainly Composed Of Drum, Screw, Differential System, Liquid Level Baffle, Drive System And Control System etc.

Feature and Advantage

-Large Aspect Ratio, High Speed With Various Angles Drum Cone

-The Feeding Screw Adopts Special Anti-Wear Measures

-Effectively Avoid The Double-Rotor High-Speed Rotation Resonance Area Phenomenon (Between 2mm/s And 4 Mm/s)

-Microcomputer Control System With Differential Speed And Torque That Can Be Automatically Adjusted With Changes In Material Concentration &Flow

-Clean Appearance

-No More Odour Generated

-Easy To Install& Operate

-Small Footprint

-Fit for Different Types of Sludge

-Selected Optional for Both Thickening & Dewatering

-Reduced Labour Cost

-More Process Flexibility Or Higher Levels Of Performance

Model Selection and Parameter Data of Horizontal Screw Centrifugal Dewatering Machine

Model	Capacity (M3/h)	Bowl Size DN*Length (mm)	Bowl Speed (RPM)	Main Power （ kw）	Dimension LWH (m)
LVD-250	0.5-3	250*900	5000	11/5.5	2.30.71.3
LVD-300	1-12	300*1350	3800	15	2.31.250.85
LVD-350	1-5	350*1500	3800	18.5/5.5	3.511.3
LVD-400	1-12	400*1800	3400	22/7.5	411.25
LVD-430	5-20	430*1800	3200	30/7.5	4.311.34
LVD-450	5-25	450*1800	3200	30/7.5	4.21.21.35
LVD-480	10-30	480*2000	3200	45/18.5	4.41.21.35
LVD-500	10-35	500*2200	3200	55/18.5	4.81.31.45
LVD-530	10-50	530*2280	2800	45/15	4.751.31.5
LVD-580	25-60	582*2800	3200	55/30	5.51.31.7
LVD-600	15-65	600*2400	2600	55/30	4.81.351.95
LVD-650	20-80	650*2600	2400	55/90	4.91.451.65
LVD-720	25-90	720*2500	2200	75/90	51.61.7
LVD-800	30-100	800*2560	2000	90/132	4.62.21.4
LVD-800	30-110	800*3200	2000	90/132	5.22.21.4
LVD-900	30-150	800*3200	1800	132/200	5.52.41.8

Working Principle 　

The drum and the screw rotate at a high speed in the same direction at a certain differential speed. The material is continuously introduced into the inner cylinder of the feeding screw from the feed pipe, and then enters the drum after being accelerated. Under the action of the centrifugal force field, the heavier solid phase is deposited on the wall of the drum. A layer of sediment is formed. The conveying screw continuously pushes the deposited solid phase to the cone end of the drum, and is discharged out of the machine through the slag discharge port. The lighter liquid phase forms an inner liquid ring, continuously overflows the drum from the overflow port at the large end of the drum, and is discharged out of the machine through the liquid discharge port.

Main Applicant for Both 2 Phase or 3 Phase Separation

-Waste Water Treatment

-Infrastructure Mud

-Food Processing

-Petrochemical

-Petroleum

-Waste Recycling

-Fish Processing

-Mineral Dressing

-Organic Chemicals

-Inorganic Chemical Industry

-Beverage Industry

-Organic Chemicals

-Polymer Industry

-Slaughter House

-Pharmacy

-Breeding Manure and Biogas Liquid

-Paint Powder, Kaolin, Plastic Scrap Recycling
