Factory Sell Maintenance-free Rotary Float Decanter For SBR CAST Pool, ETP, WWTP

 

Factory Sell Maintenance-free Rotary Float Decanter For SBR CAST Pool, ETP, WWTP

Payment Type: TT , DP, LC

Supply Ability: 50 Sets Per month

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Feature & Performance

-Decanter and Outlet Pipe connected flexibly

-Decanter Hole Layout under Its Surface Averagely

-Automatic Closing Mechanism Based On Gravitation and Flow.

-Designed without Conventional Valves And Pumps.

-No Sludge Layer Disturbance from Decanter Pipe Due To Max. Distance By

Vertical Free Movement

-Low Power Consumption with Motor Power between 0.37kw and 1.5 KW

-Running Stably and Maintaining Easily

-Auto Center, Remote Control and Field Manual Control

-Automatic Speed Change and Return (2-3 times)

-Low Operating Cost.

-Compact Structure, Simple Operation

Applicant

Filtering The Upper Clean Filtrate of SBR/CAST Reactor Tank

Why us?

-Factory Long History Directly Sales Cost and Fast Delivery

-Fully Combined Sewage Treatment Solution Design And Fabrication

-Fully Automatic System with Long Life Work Protection

-Special Matured 4 rids Collecting Design

-Customer OEM Service and Flexible Adjusting

-Good Quality Control and Training System

-Large Domestic And Overseas Performance Sites

-Within 8 Hours Response Service and After Sales Service

Main Decanter Technical Parameter Data

Model Flow(m³/h) Decanter Depth(m) Outlet Weir length(m) Outlet Pipe DN (mm) Drive Power(kw)

LSD100 100 1~3 1 200 0.37

LSD200 200 1~3 2 300 0.37

LSD300 300 1~3 2.7 350 0.37

LSD400 400 1~3 3.5 400 0.37

LSD500 500 1~3 4.2 500 0.37

LSD600 600 1~3 5.2 500 0.55

LSD700 700 1~3 6 600 0.55

LSD800 800 1~3 7 600 0.55

LSD1000 1000 1~4.5 8.2 600 1.1

LSD1250 1250 1~4.5 10 700 1.1

LSD1500 1500 1~4.5 12 600*2 1.1

LSD1750 1750 1~4.5 14.5 600*2 1.1

LSD2000 2000 1~4.5 16 700*2 1.1

LSD2500 2500 1~4.5 20 700*2 1.1

LSD3000 3000 1~4.5 24 800*2 1.5

Product Description

Packaging & Delivery

Wooden Box packing or customized
