LIS Series Slope Manure Solid-Liquid Separator

 

LIS Series Slope Manure Solid-Liquid Separator

Payment Type: T/T

Supply Ability: 30 Sets Per Month

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LIS-20

Brand: Loren

Place Of Origin: China

Key Function: Manure Separation From Water

Compacted Manure Slag Moisture: 40%-60&

Remove Debris Size: Over 150μm

Screw Compactor: Make Manure slag More Dry

Large: Treating Capacity

Compact Structure: Design with Light Weight

Separation Performance: Excellent

Without: Blocking and Secondary Pollution

Maintenance: Easy

Technology: Virbration with Gravity Act

Product Description

LIS Series Slope Manure Solid-Liquid Separator

Farming Manure Separator Definition

LIS Series Water Cutting Slope Manure Solid-Liquid Separator is

A Continuous Solid-Liquid Separator, Suitable For The Separation Of Livestock And Poultry Feces, Fruit Juice Pressing, Continuous Dehydration Equipment For Screw Pressing.

Features of Aquaculture Breeding Manure Separator

-Take Advantage of Water Flow Gravity Action

-The TSS Removal Ratio In Sewage Over 90%

-The Compacted Manure Slag Moisture Lower Than 60%

-Can Remove Debris Size Over 150μm

-Optional Choice Gap:0.15,0.25,0.5,1.0,1.5,2.0,3 mm

-Capacity Has a Positive Linear Relationship With The Gap & Screen Width

-Screw Compactor Make Manure More Dry

-Large Treating Capacity Of Single Unit

-Compact Structure

-Lower Energy Consumption

-Working Stably

-Excellent Solid Liquid Separation Performance

-No Blocking and No Secondary Pollution

-Easy For Maintenance

-Stainless Steel Structure Assure High Mechanic Strength

Inclined Screen Solid-Liquid Separation Working Principle

The Vibrating Solid-Liquid Separator Is Based On The Principle Of Physical Separation. It Is Designed To Use The Method Of Combining The Vibration System, The Feeding Extrusion System And The Automatic Flushing System To Treat The Feces And Sewage From Livestock And Poultry Farms. The Liquid Is Separated Into Solid And Liquid, And The Separated Feces Can Be Directly Packaged And Shipped Out, And The Subsequent Treatment Cost Of The Separated Liquid Is Reduced.

Applicant of Water Cutting Slope Solid-Liquid Separator

It Can be used for the Following Function Such As

-Digester or Biogas Tank

-The Primary Treating Process to Replace Sedimentation Tank

-Strengthening The Biological Treating Process

-Solid-Liquid Separation

-Slag Concentration

Typical Application Industry Below

-Paper-Making Industry--Recycling Fiber, Removing Solids

-Tannery Wastewater-- Removing Feather, Oil & Grease

-Slaughterhouse Wastewater-- Removing Bag, Fur, Grease & Feces

-Municipal wastewater -- Removing Fur, Debris

-Alcohol Plant & Starch Factory --Removal Vegetable Fibre, Hulls, Groceries -Sugar Processing Plant

-Food Processing Factory

-Textile Industry

- Printing & Dyeing Factory

-Petrochemical Plant

-Small Drainage Project Pretreatment

-Sludge or River Cure Pretreatment

Main Component

It Is Composed Of Main Engine, Cutting Type Submerged Pump, Control Cabinet, Pipeline And Other Equipment

Specification and Model Data

Model	Capacity ( m3/h)	Mesh Gap ( m3/h)	Drive Power (KW)	Vibration Power ( KW)
LIS-10	10	0.1-3 mm	2.2-4.0	0.12-0.25
LIS-20	20	0.1-3 mm	2.2-3.0	0.12-0.25
LIS-40	40	0.1-3 mm	2.2-3.0	0.12-0.25
LIS-60	60	0.1-3 mm	3.0-4.0	0.12-0.25
LIS-100	100	0.1-3 mm	4.0-5.5	0.12-0.25
LIS-120	120	0.1-3 mm	4.0-5.5	0.12-0.25

The Above Data is only for Reference
