LPE Series Barrel Chemical Dosing Tank

Payment Type: T/T

Supply Ability: 200 sets per months

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LPE-1000

Brand: Loren

Old And New: New

Applicable Industry: Hotels, Farms, Food &Amp; Beverage Shops, Garment Shops, Restaurant, Building Material Shops, Manufacturing Plant, Food Shop, Machinery Repair Shops, Printing Shops, Construction Works, Food &Amp; Beverage Factory, Energy &Amp; Mining

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Pressure Vessel, Pump

Place Of Origin: China

Warranty Period: 1 Year

Core Selling Point: Competitive Price

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Simple: Structure

High: Dosing Accuracy, Strength & toughness.

Excellent: Rigidity

Heat And Cold Resistance: Function

Anti-aging And Anti-UV: Feature

Easy For: Installation, Operation& Maintenance.

Optional With: Metering Pumps and Pipe or gause

Long: Service Life

Special OEM: Available

Product Description

LPE Series Barrel Chemical Dosing Tank

Definition of PH Chlorine Flocculant Dosing Equipment

Integrated Chemical Dosing System Is Mainly Consist Of Doing Pump, Which Put Chemical Dissolving Tank, Agitation, Dosing Unit, Level Switch,Safe Valve, Check Valve,Pressure Gauge, Filter, Buffer,Pipe, Valve, Base, Ladder,Automatic Monitoring System, Electric Control System On The Public Platform. This Will Form a Module, Namely Skid-Mounted System.

The Chemical Dosage And Pressure Can Be Adjusted Based On The Industrial Process Requirements By Selecting Correct Dosing Pump. The Flow Rate Can Be Choosed From 1l/h To 8000l/h. And The Pressure Can Be Choosed From 0.1mpa To 25mpa. Based On The Different Transmission Medium, There Are Many Kinds Of Material To Choose. .

Working Principle of 1000L PAC PAM Liquid Container Dosing Device

According to The Chemical Concentration, The Dosing Unit Will Prepare The Chemical Liquid In The Agitating Tank. After The Agitation, The Liquid Will Be Put Into The Dissolving Tank. By Using Metering Pump(Dosing Pump), The Solution Can Be Carried Into Dosing Point Or Required System

Anti-Acid/Alkali Plastic Chemical Dosing System Features
-High Dosing Accuracy
-Easy For Installation, Operation& Maintenance.
-High Operational Reliability.

-High Strength & High toughness.

-Good Rigidity

-Heat and Cold Resistance

-Anti-aging and Anti-UV

-Compact Structure with Small Volume

-Low Noise

-Long Service Life

(All Customized Models Are Available By Online Inquiry).

Main Technical Parameter & Model Selection

Model	Capacity ( (L/h)	Power Thickness (mm)	Dimension (mm)
LPE40	40	3.5	DN350*420
LPE60	60	4.0	DN460*480
LPE80	80	4.5	DN460*600
LPE100	100	5.0	DN460*750
LPE200	200	5.0	DN580*970
LPE300	300	5.0	DN650*1000
LPE500	500	5.0	DN810*1150
LPE1000	1000	6.0	DN1050*1350
LPE1500	1500	7.0	DN1210*1650
LPE2000	2000	8.0	DN1360*1600
LPE3000	3000	10	DN1600*1920
LPE5000	5000	11	DN1850*2380
LPE6000	6000	11	DN2000*2500
LPE8000	8000	11	DN2160*2750
LPE10000	10000	12	DN2300*2980
LPE15000	15000	14	DN2650*3400
LPE20000	20000	16	DN3000*3500
LPE25000	25000	20	DN3000*4250
LPE30000	30000	21	DN3400*4150
LPE40000	40000	25	DN3400*5170
LPE50000	50000	31	DN3400*6720

Comment: Mixer Power: 0.18/0.37/0.55/0.75/1.1/1.5/2.2/3/4/5.5KW
