LLE Series Waste Liquid Low Temperature Evaporator

 

LLE Series Waste Liquid Low Temperature Evaporator

Payment Type: T/T

Supply Ability: 15 Sets per months

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LLE-300

Brand: Loren

Place Of Origin: China

Main Function: Reduction of Waste Liquid Concentration

Fit For: High Density and TDS Waste Liquid

Heat Transfer Temperature Difference: about 2 Degree Cecus

Special: Adjustable Steam Thermal Compression Device

Adopts: Internationally Advanced Air Flow Tee

Customized Design: Compact solution

Longevity: optional structure in different serve life

Carry On: Key Parts Modification and Test

Intelligent Control System: Fully Automatic Control ing

OEM , ODM Service: Available

Product Description

LLE Series Waste Liquid Low Temperature Evaporator

Loren Evaporator Features

-The Effective Heat Transfer Temperature Difference Is Controlled At About 2°C

-Reduce the Total Discharge Volume Of Waste Liquid

-Save Fresh Water Resource

-Adopts Steam Thermal Compression Device With Adjustable Ejection Coefficient

-Adopts Full Precision Heat Transfer Tube

-Adopts Internationally Advanced Air Flow Tee

-Carries on Key Parts Modification and Test

-Realize Intelligent Control System

Application Industry

-Cutting Fluid Wastewater

-Polishing Fluid Wastewater

-Cleaning Wastewater

-Release Agent Wastewater

-Emulsion Wastewater

The Specific Configuration Includes The Low-Temperature Evaporation Equipment Body, The Pre-Treatment Oil-Water Separation Device, The Post-Treatment Membrane System (Optional) And Related Auxiliary Equipment.

Technical Parameters

Model	Capacity L/H(D)	Total Power (kw.H)	Energy Consumption KWh/m3	Outline Dimension (mm)
LLE-300	10/300	3	169	15009001640
LLE-500	22/500	4	169	183015802400
LLE-1000	50/1000	9	165	183015802400
LLE-2000	100/2000	18	160	258014301790
LLE-3000	150/3000	23.5	160	258014701930
LLE-5000	250/5000	38.8	155	320019002740
LLE-10000	300/10000	52.6	150	456028803150

Note: The Evaporator Size and weight will differ from the parameter change

Working Principle

The heat generated by the closed-loop refrigeration circuit of the heat pump is used to separate the water from the concentrate under vacuum pressure below -0.99Mpa based heating water from below 30 ℃

Heat Exchange Principle

In Order To Avoid Excessive Boiling And Affect The Quality Of The Distillate, The Liquid Is First Sent To The Bottom Of The Heater For Heating Before Passing Through The Auxiliary Exchanger To Be Cooled By Air. The First Stage Of Distillate Obtained At This Time Is The Conversion Of The Waste Liquid From Liquid To Vapor Conditions And Saturated At High Pressure. The Liquid Comes Out Of The Heating Converter And Then Passes Through The Main Exchanger To Be Cooled By Air. Before Reaching The Second Heat Exchanger, The Liquid In The Condensation Chamber Is Diffused Through a Thermostatic Valve. The Steam Generated In The Distillation System Releases Heat To Cool The Liquid Through The Thermostatic Valve. The Distillate Produced By The Above Heat Exchange Is Discharged Through a Centrifugal Pump. The Refrigeration Cycle Of This Equipment Uses Ecological Refrigerant (r407c).

Composition

It is automatically controlled by PLC and consists of heating tank, cold water tank, compressor, heat exchanger, cold row, suction pump and electrical control components.
