SS Series Rake Bar Screen

Payment Type: T/T

Supply Ability: 200 Sets per Month

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LRS-600

Brand: Loren

Place Of Origin: China

Main Structure: Stainless Steel

Slot Optional Range: 1-15mm

Performance: Removal Particle or TSS or Trash In Water, Excellent Quick and Continuous High Efficiency

Teeth Opening Space: Can be Adjustable

Optional Choose: Cover , Spare Parts

With: Little Clogging or No Clogging

OEM, ODM: Available

Supporting Process: Provided

Control System: Fully Auto with Stable Wo

Product Description

Definition of Stainless Steel Rake Bar Screen

LRS Series Rotary Rake Bar Mechanical Screen Is A General Advanced Continuous Auto Sundries Intercepting & Removing Grille for Water Solid Treatment, It is an Idea Solid Liquid Separation Machine

Working Principle of Stainless Steel Rotary Mechanical Grille

Groups of Rake Bar Run Counter Flow Direction Under Reducer Driving, When Reaching to Its Up, Each Rake Teeth Bar Group will Carry on Self-Cleaning Working Under the The Direction Of Sheave & Burr Wheel, Meanwhile Most Solid Materials Falls Down By Gravity. The Other Solids Attaching On The Rake Will be Tidy Out Under The Opposite Direction Of Sweeper. The Whole Circle Movement Can Be Continuous or Sequence as per Actual Requirement

Feature of Stainless Steel Mechanical Bar Screen

-Higher Separation Efficiency

-Higher Auto Run Degree

-Little Load and Electricity Consumption

-Little Noise

-Overload Safety Protection

-Rake Teeth Material Can be Nylon or Steel

-Rake Opening Gap Can be Adjustable for Different Water Fluctuation

-Self Clean Performance with Little Clogging

Applicant

-Municipal Sewage Treatment

-Tap Waste Water (Waterworks )

-Electricity & Power Plant

-Textile

-Dyeing and Printing

-Food Processing

-Paper Mill

-Leather Processing

-Aquaculture

-Slaughtering House

-Tannery Industry

Specification

Model	Screen Width (mm)	Channel Width (mm)	Water Volume (M3)	Power (kw)	Rake Gap (mm)
LRS-300	300	400	150-460	0.37	1-15
LRS-400	400	500	170-540	0.37	1-15
LRS-500	500	600	240-750	0.55	1-15
LRS-600	600	700	308-960	0.55	1-15
LRS-700	700	800	360-1160	0.55	1-15
LRS-800	800	900	440-1420	0.75	1-15
LRS-900	900	1000	550-1580	0.55	1-15
LRS-1000	1000	1100	580-1830	0.55	1-15
LRS-1100	1100	1200	650-2080	1.10	1-15
LRS-1200	1200	1300	710-2250	1.10	1-15
LRS-1300	1300	1400	780-2310	1.50	1-15
