Free Maintenance High Efficiency Filter

Payment Type: T/T

Supply Ability: 50 Sets Per Month

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LFMF-20/30

Brand: Loren

Status: New

Applicable Industry: Hotels, Farms, Food &Amp; Beverage Shops, Garment Shops, Restaurant, Building Material Shops, Home Use, Other, Retail, Advertising Company, Food Shop, Manufacturing Plant, Printing Shops, Machinery Repair Shops, Construction Works, Food &Amp; Beverage Factory, Energy &Amp; Mining

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 3 Years

Core Components: Pressure Vessel, Plc

Place Of Origin: China

Warranty Period: 3 Years

Productivity: 500l/Hour, 100l/Hour, 10000l/Hour, 1000l/Hour, 20000l/Hour, 750l/Hour, 2000l/Hour, 250l/Hour, 3000l/Hour, 125l/Hour, 200l/Hour, 4000l/Hour, 5000l/Hour, 7500l/Hour, 50000l/Hour, 2500l/Hour

More And High Economical Value: Large Capacity of Sewage

Excellent Elastic Media: Graphene Composites

Back-washing Water Volume: 1/20 of Other Type Filter

Small Body Room: 1/4 of Actovated Carbon Filter

Can Combined Run: in Group Set simutanously

Can Replace: UF, Mechanical Filter, Fiber Filter etc

Outlet SS: can Below 0.5Um

Esp: for Waterworks and RO Recycling Water upgrading

Essential Function: Last Process Qualified Water Guarantee

OEM ODM Service: Available

Product Description

Graphene Composites Maintenance Free Filter

Definition of High Efficiency Maintenance Free Filter

FMF Series Filter is large-capacity filtering equipment that can perform ultra-high-speed processing operations. It makes up for the shortcomings of filters commonly used in china and greatly improves the filtration efficiency. It is a new type of water filter with main purpose of removing suspended matter. Our company has successfully applied for a national patent for this filter.

Fully Automation and Ultra High Speed Filter FMF Filter Packing

Shape	Multiple Angle Floatable Filter Module
Dimension	5mm5mm3mm
Material	PP Or PS
Porosity	90-94%
Specific Gravity	0.85-0.95
Pore Diameter	φ5-70µm
Rate of the Nurgle	10Kg-SS/m3
Specific Surface Area	8000m2/m3

FMF Filter Feature

-Fits for All kinds of Filter (Upflow, Downflow etc.)-Time and Water Saving for Agitating and Backwashing Back-washing Water Volume is 1/20 of the Traditional One

Backwash Time:8-9 Minutes/Cycle Per Day -Excellent Deep Filtration Efficiency Forms a 1000 mm Layer to Achieve Deep Filtration. Performance Duration Depends on its Filter Module Volume -With Three-Dimensional Porosity It Can Reduce Pressure Lost and Save Energy with Super Higher Filtration Speed (For Low Voltage: 40-70 m/h;

For Quartz Sand Filter: 10-15 m/h)-Compact Structure No Need Other Separated Backwash Pump Or

Storage Device, so it occupies very Small Room With Light Weight : Compared with Sand Filter:

Whose Body is 1/8; DN is 2/5 and

Room is ¼ of that Sand Filter .

Model Selection and Parameter

Model	Capacity( M3)	Agitator (kw)	DN*H (mm)	N.W.(kg)
FMF-20	20	1.5	600*2600	680
FMF-40	40	3.7	850*2705	935
FMF-70	70	5.5	1150*3035	1550
FMF-140	140	11.0	1600*3320	2650
FMF-210	210	18.5	2000*3725	4250
FMF-350	350	30.0	2600*4200	6000

Comparison With Other Large Filters

Item	V-Shape Filter	Fiber Filter	Filter Pool	Fiber Turntable Filter	Flap Filter	High Speed FMF Filter
Speed （m/h）	7-15	18-20	20-26	9-12	6-10	40-70
Filler Layer Thickness （m）	1.2-1.5	0.8-1.2	0.8-1.2	——	1.5	1
Accuracy （µm）	15	10	5	10	15	1
Backwash Time and Period	20min （24h）	15-20min (24h)	15-20min (8-24h)	1-2min （1-2h）	20min (36h)	8min (24h)
Backwash water accounts for % of Daily Treatment	5-6	2-5	5-9	5-7	5-6	0.5
SS Removal Ratio %	70-90	80-90	90-95	90-95	70-80	Over 98
Cost per Ton Water	100-120 ¥	75-85¥	100¥	85-100¥	120-150¥	85¥
Foot Print （50000 M3）	200m2	165m2	100m2	80m2	240m2	75m2

Applicant in Below Field

★Sewage Treatment Plant Depth Treatment

★Gray Water & Swimming Pool Water Treatment

★River Water, Lake Water And Rain Water Treatment

★water Works filtration treatment

★Aquaculture Water Purification Treatment

★Industrial Wastewater Recycling Filtration Treatment

★Cooling Circulating Water Treatment But Not Limited To Above
