Grit Separator Sand Removal System

Payment Type: T/T

Supply Ability: 100 Sets Per month

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LGS-420

Brand: Loren

Applicable Industry: Hotels, Farms, Food &Amp; Beverage Shops, Restaurant, Home Use, Building Material Shops, Manufacturing Plant, Food Shop, Machinery Repair Shops, Construction Works, Food &Amp; Beverage Factory, Energy &Amp; Mining

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Pressure Vessel

Old And New: New

Place Of Origin: China

Warranty Period: 3 Years

Service System: Online Support

V-shaped Barrier Plate Outflow: Make sure Compact Room

Single Unit Capacity: 126 CMB per Hour

Filteration Grit Size: ≥0.2mm

Fitration Efficiency: 98%.

Dimension Or Material: As per Site real requirement

OEM, ODM Serive: available

Essential Function: Purifying Grit or Sand In The Water

No: clogging And Overload Phenomenon

After Sale Service: Within 8 Hours Response

Product Description

LGS Series Model Screw Grit Classifier or Separator

Grit Classifier System Definition

It Is a High & Economical Grit Water Separator which is mainly composed of U-shaped groove, spiral blades, driving devices etc by fixing it on the civil foundation of concrete.

LGS Type Spiral Sand Water Separator Brief Function

V-shaped Barrier Plate Outflow Ensures The Minimum Grit Content In The Water

Shaft-Less Spiral Grit Separation To Avoid Clogging And Overload Phenomenon

U-liner Adopts High-Quality Engineering Plastics Molding With Good Wear Resistance Function

Feature and Characteristic

-With a maximum single capacity as 126 m3/ h

-Baffled V-shaped weir outflow ensures the minimum Grit content in the water

-Shaft-less spiral Grit separation to avoid clogging and overload phenomenon

-U-type liner selects high-quality plastic molding with good wear resistance

-Low-speed operation with lower energy consumption and little swear

-Spiral material optional: high strength alloy steel, SS304 or SS316L

-Frame shell material optional: stainless steel SS304 or SS316L

-Optional: pre-set swirl separator

Working Principal

The mixture (Grit / liquid) enters the tank through the water inlet pipe above the tank. The larger specific gravity of the fluid, such as Grit particles, precipitates at the bottom of the trough. Under the push of the spiral blade, the Grit particles are lifted along the inclined U-shaped bottom of the trough. After leaving the liquid surface, continue to move for a certain distance, after the Grit particles are fully dehydrated, the Grit is transported to the high-end discharge truck by spiral conveying, and the water separated from the Grit is discharged from the overflow port to achieve the purpose of Grit and water separation. Before the overflow of the water tank, the solid matter separation rate of particle size ≥0.2mm reached 98%.

Applicant

-Sewage Treatment Plant

-Municipal STP

-Electronic Distilled Water Purifier

-Industrial Waste Water Purifier

-As Biological Agent Fermentation Tank Supernatant Treatment Device

-As Impurity Removal Device For Circulatory Systems Like Bottle Washing Machines

-Preparation Engineering Of Drinking Pure Water

-As Filter Media For Drain Pumps Or Mud Pumps

-Pharmacy

-River Water

-Hotel or Restaurant

-Airport

-Industrial Mineral Processing,

-Solid-Liquid Separation

References & Implementation Standards

Q / 320282AAH005-2000 Grit Removal Machine

Q / 320282AAH004-2000 Grit Water Separator

ISO9001 Quality Management System Standard

GB50231 General Specifications for Construction and Acceptance of Mechanical Equipment Installation Projects

SZ-06-99 Quality Inspection and Evaluation Standard for Electromechanical Equipment Installation of Drainage Engineering

grit separator Model Selection and Parameter

Model	LGS-260	LGS-320	LGS-355	LGS-420
L(mm)	4350	4770	6350	6700
L1(mm)	3840	4380	5890	6290
L2(mm)	3000		4000
L3(mm)	1000	1500	2000	2500
W(mm)	1653	1748	1880	1920
H(mm)	2100	2350	3050	3250
H1(mm)	1670	1860	2480	2590
H2(mm)	1600	1800	2250	2250
B(mm)	1260	1340	1506	1800
A1(mm)	2700	2800	3900	3800
A2(mm)	150
Water inlet (mm)	Φ100	Φ150	Φ200	Φ200
Overflow (mm)	Φ150	Φ200	Φ250	Φ250
