LDF Series Disc Filter

Payment Type: T/T

Supply Ability: 50 Sets Per Month

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LDF3-4

Brand: Loren

Status: New

Applicable Industry: Food &Amp; Beverage Shops, Building Material Shops, Manufacturing Plant, Food Shop, Machinery Repair Shops, Food &Amp; Beverage Factory, Energy &Amp; Mining, Construction Works

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Pressure Vessel

Place Of Origin: China

Warranty Period: 1 Year

Productivity: 10000l/Hour, 500l/Hour, 100l/Hour, 750l/Hour, 1000l/Hour, 20000l/Hour, 2000l/Hour, 250l/Hour, 3000l/Hour, 125l/Hour, 200l/Hour, 4000l/Hour, 5000l/Hour, 7500l/Hour, 50000l/Hour, 2500l/Hour

Essential Function: Disc Laminated Pressure Filtration

Filter Accuracy: 20/55/100/130/200/400µm

Filtration Ratio: >85%

Back Washing Time: Within 20 Seconds

Running: Fully Auto Filtering and Backwashing

Maintenance: Easy with no special tool

Life Time: Longevity

Design: Module setting

OEM ODM Service: Available any time

After Sale Service: Within 8 hours response an

Product Description

LDF Series Disc Filter

Laminated Filter Feature & Characteristic

-Precise Filtration with Range: 20/55/100/130/200/400µm

-Filtration Ratio>85%

-Thoroughly High Efficiency Back Washing with 10-20 Seconds Time

-Fully Automatic Running and Continuously Water Output

-Module Design to Flexibly Add New Alternative Choice

-Easy Maintenance , No need Special Tool

-Long life Time

Irritation Filter Applicant

- Irrigation

-Cooling Tower Circulated Water Bypass

-Intermediate Water Recycling Use.

-Waste Water Treatment

-Sea Water Desalination Primary Treatment

-Primary Treatment Before UF or RO

-Sewage Regeneration

-Municipal STP

-Waterworks

-Large Electricity Generation Plant

-Chemistry

-Emergency Filter

-Steel and other Metallurgy

-Food and Beverage Processing

-Paper mill and Textile as well as Plastic Industry

-Mining Exploitation

Working Principle

It is composed of a group of compacted and Laminated Filters. During Water Filtration , Suspend solid will stay on two Disc Inter-crossing Points ,while the Filtrated Water will Flow out through Their Main Channels. When Pressure Difference Reach to Set Value , It Will Carry On Auto Back Washing Period by Closing Main Channel Single Direction Valves through Controller and the Back washing Enter Groups Nozzles Channel to Push over the piston to carry on High-speed injection in the direction of the lamination tangent to tidy the debris among Disc inter-crossing Area , After That , the water flow direction also changes ,the disc will recover laminated status thus to enter into filtration process to make it as a circulation working.

Disc Filter Parameter One

Raw Water	Fine Water Quality					Normal Water Quality					Dimension (LWH) (mm)
Level(µm)	200	130	100	50	20	200	130	100	50	20
Model	Flow Volume ( M3/h)					Flow Volume ( M3/h)
LDF2-3	75	66	60	42	21	57	50	45	33	15	12557191300
LDF2-4	100	88	80	56	28	76	66	60	44	20	15557191300
LDF2-5	125	110	100	60	35	95	83	75	55	25	18557191300
LDF3-3	111	100	90	60	30	84	73	66	48	22	8158651360
LDF3-4	148	132	120	80	40	112	97	88	64	30	11158651360
LDF3-5	185	165	150	100	50	140	121	110	80	37	14158651360
LDF3-6	222	198	180	120	60	168	145	132	96	45	17158651360
LDF3-7	259	231	210	140	70	196	169	154	112	52	20158651360
LDF3-8	296	264	240	160	80	224	194	176	128	60	231586513600
LDF3-9	333	297	270	180	90	252	218	198	144	67	26158651360
LDF3-10	370	330	300	200	100	280	231	210	160	75	29158651360
LDF4-3	296	264	240	160	80	224	194	176	128	60	20006002400
LDF4-4	370	330	300	200	100	280	231	210	160	75	26006002400
LDF4-5	494	441	401	267	134	374	323	294	214	100	32006002400
LDF4-6	592	528	480	320	160	448	387	352	256	120	38006002400

Disc Filter Parameter Two

Raw Water	Bad Water Quality					Worst Water Quality					Dimension (LWH) (mm)
Level(µm)	200	130	100	50	20	200	130	100	50	20
Model	Flow Volume ( M3/h)					Flow Volume ( M3/h)
LDF2-3	40	33	30	22	10	24	21	19	13	7	12557191300
LDF2-4	54	44	40	30	14	32	29	26	18	10	15557191300
LDF2-5	67	55	50	37	17	40	35	32	22	12	18557191300
LDF3-3	60	50	45	33	15	36	31	28	19	10	8158651360
LDF3-4	80	66	60	44	20	48	41	37	26	14	11158651360
LDF3-5	100	83	75	55	25	60	52	47	32	17	14158651360
LDF3-6	120	99	90	66	30	75	62	56	39	21	17158651360
LDF3-7	140	116	105	77	35	84	73	66	45	24	20158651360
LDF3-8	160	132	120	88	40	96	83	75	52	28	23158651360
LDF3-9	180	149	135	99	45	108	94	85	58	31	26158651360
LDF3-10	200	165	150	110	50	120	103	94	65	35	29158651360
LDF4-3	160	132	120	88	40	96	83	75	52	28	20006002400
LDF4-4	200	165	150	110	50	120	103	94	65	35	26006002400
LDF4-5	267	220	200	147	67	160	138	125	87	47	32006002400
LDF4-6	320	264	240	176	80	192	165	150	104	56	38006002400
