High Efficiency Activated Carbon Filter

Payment Type: T/T

Supply Ability: 50 Sets per month

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LACF-320

Brand: Loren

Applicable Industry: Food &Amp; Beverage Factory, Energy &Amp; Mining, Construction Works, Manufacturing Plant, Food &Amp; Beverage Shops, Restaurant, Garment Shops

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Pressure Vessel

Old And New: New

Place Of Origin: China

Warranty Period: 1 Year

Service System: Online Support

Specific Surface Area: 1000㎡/g

Backwash Strength: 4-15l/s·㎡

Backwash Time: 5-7 Minutes

Little Fault: Only Backwashing drive

Can Accept TSS Inlet: 150-300mg/L

Easy For: Upgrading

Oem, ODM Service: Available

Can Customized Deisng: online Carbon Regenerat

Product Description

ACF Series High Efficiency Activated Carbon Filter

Feature and Performance of Automated mechanical filter Helps Water Purifier Performance

-Highly Reduce COD and Disaffection As Well As Other Pollutant

-Can be Designed as AC Regeneration online

-Upper Water Inlet From is Mother And Branch Pipes Design .

-Down-forward Water Outlet Form Is Perforated Plates Water Cap

-With On-Site Sampling Device and Water Pressure Gauges.

Applicant of The Activated Carbon Filter

-Remove Macro-molecular Organic Matter In Water

-Remove Iron Oxides In Water

-Remove Residual Oxygen In Water

-Remove Organic Matter In Water

-Remove Iron Oxide In Water

-Prevent Ion Exchange Resin Poisoning (Disinfection)

Function

Visionary User Should Emphasis The Function Of Activated Carbon Filter In The Selection Of Water Treatment Processes Or Devices Because The Solubility Of The Organic Polymer And Colloidal Substances And Other Substances Are Often Negatively Charged, Often Adsorbed In The Anion Resin Particle Surfaces, And Then Spread Into The Resin Network Structure, Entangled In The Cross-Linking Degree Of The Resin And Covering a Portion Where Ion Exchange Functional Groups, The Normal Migration Of Ions Interfere With Freedom. While Its Analytical Ability, And Ion Exchange Resin Membrane (Electrolysis Membrane) Caused By Pollution, The Reverse Osmosis Membrane Surface Can Be Blocked Or Loss Of Activity. Even Some Dissolved Organic Matter And Have a Strong Affinity Resins, Acid Substitution Can Not Be Recycled, It Will Lead To An Ion-Exchange Membrane In Particular Anion Exchange Membranes And Anion Exchange Resin Poisoning Failure.

Activated Carbon Filter Parameter

SN	Model	Filter DN (mm)	Filter Area m2	Flow M3/H	Dimension mm	Filter Speed	AC Layer Height mm
1	LACF-30	300	0.07	0.7	DN400*2102	8-10 m/h	1400
2	LACF-40	400	0.125	1.25	DN535*2720	8-10 m/h	1800
3	LACF-50	500	0.196	1.96	DN635*3160	8-10 m/h	2000
4	LACF-60	600	0.283	2.80	DN750*3265	8-10 m/h	2000
5	LACF-80	800	0.502	5.0	DN980*3335	8-10 m/h	2000
7	LACF-100	1000	0.785	7.8	DN1220*3600	8-10 m/h	2000
8	LACF-150	1500	1.76	17.6	DN2020*6430	8-10 m/h	2000
9	LACF-200	2500	4.90	50	DN2524*6460	8-10 m/h	2000
10	LACF-250	3000	7.1	70	DN3028*6590	8-10 m/h	2000
11	LACF-320	3200	8.1	80	DN3224*4200	8-10 m/h	2000

Comment:

- The Valve normally Provided By user , if needed , specify when ordering

- Restart The Filter After Long Time Stop, Before Reuse , Flushing The AC

Media For 5 Minuets Till The Water Become Clear Again.

- Restart The Filter After Long Time Stop, Before Reuse ,Open The Air Valve

and Water Inlet Till The Air Valve Outlet Water Has No Air

- Large Filter Use air(strength 8L/m2 S) Scrubbing To Enhance The

Back washing Effect before Air-Water Back-washing

- The AC Media Should Be Replaced Regularly ( Usually Every 3-6 Months)

as Per Water Quality .
