Loren LOC Series White Clay Oil Compactor

 

Loren LOC Series White Clay Oil Compactor

Payment Type: T/T

Supply Ability: 25 Sets per Three Months

Contact Now

Product Attributes Supply Ability & Additional Information

Product Attributes

Model No.: LOC-500

Brand: Loren

Applicable Industry: Farms, Hotels, Food &Amp; Beverage Shops, Restaurant, Home Use, Machinery Repair Shops, Food Shop, Construction Works, Food &Amp; Beverage Factory, Energy &Amp; Mining, Other

Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Gearbox, Engine

Old And New State: New

Place Of Origin: China

Warranty Period: 2 Years

Unique Selling Point: Low Maintenance Cost

Compacting Way: upright Hydraulic Hammer

Essential Fuction: Oil Compacting and Recycled

High Oil Yield: Large Productivities of Oil Collection

Design: Economical and Reasonable

Maintenance: Easy

Footprint: Small

Operation: Simple and Easy

Energy Consumption: Competitive

Labor Work: Light and Simple

Multiple Function: Oil Reuse, Sludge Dewate

Product Description

Loren LOC Series White Clay Oil Compactor

Cooking Oil Water Separator Definition

It Is a A high Oil Yield Waste White Clay Soil Pressing Machine with a dual-acting oil cylinders as the main pressing part, which is preheated and then pressed

Lubricated Fuel Oil Purifier Feature

-Special Design for White Clay Compacting

-High Oil Yield Ratio

-Economical and Reasonable Design

-Easy Maintenance

-Small Footprint

-Simple Operation

-Highly Automation

-Little Energy Consumption

-Little Labor Work

-Cost Saving

Working Principle of Upright Oily Sludge Separator

Use Two Upright Liquid Hydraulic Cylinder as hammer for pressing and compacting the white clay , oily sludge material likewise to make the outlet oil or sludge as per demand

Main Configuration of LOC-500 Clay Compactor

White Clay Yield Volume:10-15 Metric Tons Per Day

White Clay Oil Content: 25-35%

Max. Run Pressure:5000KN

Motor Power:11 KW

Main Oil Cylinder Stroke:1000mm

Push Oil Cylinder Stroke:1500mm

Working Height:1400mm

Work Platform No.: 2 ( Alternative Work)

Work Platform Dimension: 1450*1450*1500mm

Filtrate Plate: 1450*1450mm 80 pcs

Filtrate Cloth: 2300*2300mm 80pcs

Single Time Compacting Weight: 1000 kgs with 90% Moisture

Dry Sludge Moisture:55-59%

System Dimension:6000 *1800 * 4200mm

Operators Needed : 2 Staff

Applicant of Fuel Oil Recycled Compactor

-White Clay

-Crude oil

-Plant Oil

-Fuel Oil

-Cooking Oil

-Industrial Sludge

-Municipal STP Sludge

-Other Materials with moisture
